Description
Features of Permanent Magnet Generator
*Low start up speed, Gearless, low RPM generator
*High standard components for use in hard and extreme
Environments for wind turbine
*High efficiency low mechanical resistance energy loss
*Design for reliable long operational lifetime
| Model | Rated power ( W ) | Rated voltage ( V ) | Rated rotated speed ( rpm ) | Startup torque ( N*M ) | Efficiency |
| LSL-50W | 50 | DC14 | 200 | 0.25 | 70% |
| LSL-100W | 100 | DC14 | 200 | 0.35 | 75% |
| LSL-200W | 200 | DC28 | 200 | 0.65 | 78% |
| LSL-300W | 300 | DC28 | 200 | 0.7 | 78% |
| LSL-500W | 500 | DC28 | 200 | 1.2 | 78% |
| LSL-1000W | 1K | DC56 | 200 | 2 | 88% |
| LSL-2000W | 2K | DC115 | 200 | 2.5 | 85% |
| LSL-3000W | 3K | DC115 | 300 | 2.5 | 85% |
| LSL-5000W | 5K | AC230 | 200 | 4 | 88% |
| LSL-10KW | 10K | AC230 | 200 | 6.5 | 90% |
| LSL-20KW | 20K | AC400 | 150 | 15 | 90% |
| LSL-50KW | 50K | AC690 | 150 | 40 | 90% |
| LSL-100KW | 100K | AC690 | 140 | 85 | 90% |
| LSL-300KW | 300K | AC690 | 350 | 185 | 90% |
