Description
Common old style single nozzle inclined jet water turbine generator is only suitable for application of high water head and small flow. Power of Coiled four-nozzle inclined jet generators are above 5 KW 15KW and suitable for customers with medium/high water head and medium/low flow. They are made for sufficient utilization of water source by switching of numbers of nozzles according to high/low water season and the actual power needed during operation. The output generated power will be multiply increased and reach that of several sets of machines with the same water head by just adjusting water flow. The permanent magnetic motor is manufactured using high-performance strong magnetic materials. The motor is equipped with load regulator to automatically regulate load of the generator and stabilize the output voltage.
Note:
1. In case conditions of water source are limited, low rotation speed, such as 750 rpm and 500 rpm, are to be selected and thus cost will be increased.
2. Special requirements: For 60Hz frequency and 110V voltage machines, custom manufacture is needed.
3. For batch finalization of 10 KW machines, they can be designed and produced according to conditions of water sources of customers (water head and flow).
Note:
1. In case conditions of water source are limited, low rotation speed, such as 750 rpm and 500 rpm, are to be selected and thus cost will be increased.
2. Special requirements: For 60Hz frequency and 110V voltage machines, custom manufacture is needed.
3. For batch finalization of 10 KW machines, they can be designed and produced according to conditions of water sources of customers (water head and flow).
| Name | Power (KW) | Water head (M) | Flow (m³/S) | Rotating speed (R/M) | Voltage(V) | Frequency (Hz) | Transmission |
| Coil pipe four nozzle incline jet water turbine generator | 5.0 | 20-50 | 0.044-0.018 | 1000/1500 | 220/380 | 50 | Direct |
| 8.0 | 22-50 | 0.064-0.028 | 1000/1500 | 220/380 | 50 | Direct | |
| 10 | 20-50 | 0.085-0.034 | 1000/1500 | 380 | 50 | Direct | |
| 12 | 20-50 | 0.099-0.04 | 1000/1500 | 380 | 50 | Direct | |
| 15 | 20-50 | 0.120-0.044 | 1000/1500 | 380 | 50 | Direct |
