Description
We offer various kinds of permanent magnetic generator from 0.1KW-1500KW(vertical and horizontal), please contact us for more detail informations.
Features of Permanent Magnet Generator
*Low start up speed, Gearless, low RPM generator
*High standard components for use in hard and extreme
Environments for wind turbine
*High efficiency low mechanical resistance energy loss
*Design for reliable long operational lifetime
| Model | Rated power (kw) | Rated speed (rpm) | Rated voltage(V) | Weight(kg) |
| XDSHF770 (OUTER) | 20.0KW | 300 | 500/380VAC | 165-180 |
| 10.0 KW | 150 | 500/380VAC | ||
| 7.5 KW | 130 | 380VAC | ||
| 5.0 KW | 80 | 380VAC | ||
| XDSHF700 (OUTER) | 10.0KW | 300 | 380VAC | 125-145 |
| 7.5 KW | 150 | 380VAC | ||
| 5.0 KW | 100 | 380VAC | ||
| 3.0 KW | 80 | 380/220VAC | ||
| XDSHF550 (OUTER/INNER) | 3.0 KW | 160 | 380VAC | 65 |
| 2.0 KW | 130 | 380/220VAC | ||
| 1.5 KW | 100 | 380/220VAC | ||
| 1.0 KW | 80 | 220VAC/56VDC | ||
| XDSHF450 (OUTER/INNER) | 2.0 KW | 180 | 380/220VAC | 48 |
| 1.0 KW | 110 | 220VAC | ||
| XDSHF380 (OUTER/INNER) | 2.0 KW | 300 | 380/220VAC | 32 |
| 1.0 KW | 180 | 220VAC | ||
| 0.5 KW | 100 | 220VAC/56VDC | ||
| XDSHF320 (OUTER/INNER) | 1.0 KW | 300 | 220VAC/56VDC | 20 |
| 0.5 KW | 200 | 56VDC | ||
| XDSHF280 (OUTER/INNER) | 0.5 KW | 300 | 56/28VDC | 15 |
| 0.3KW | 200 | 56/28VDC | ||
| XDSHF260 (OUTER/INNER) | 0.3 KW | 300 | 56/28VDC | 11 |
| 0.2 KW | 200 | 28VDC | ||
| 0.1 KW | 130 | 28/14VDC | ||
| XDSHF220 (OUTER) | 0.2 KW | 300 | 28/14VDC | 8.5 |
| 0.1 KW | 200 | 28/14VDC | ||
| XDSHF200 (OUTER) | 0.1 KW | 300 | 28/14VDC | 5.8 |
| 0.05 KW | 200 | 14VDC | ||
| XDSHF165 (INNER) XDSHF150 (OUTER) | 0.3 KW | 1200 | 28VDC | 3.8 |
| 0.1 KW | 500 | 14VDC | ||
| 0.05 KW | 300 | 14VDC | ||
| XDSHF125 | 0.05 KW | 800 | 14VDC | 1.0 |
