Description
We offer various kinds of permanent magnetic generator from 0.1KW-1500KW(vertical and horizontal), speed from 30rpm-6000rpm, output voltage and speed can customize according your request
Features of Permanent Magnet Generator
*Low start up speed, Gearless, low RPM generator
*High standard components for use in hard and extreme
Environments for wind turbine
*High efficiency low mechanical resistance energy loss
*Design for reliable long operational lifetime
Power(KW)
AC voltage(V)
speed(RPM)
Rated torque(NM)
Start torque(NM)
current(A)
efficiency
weight
60
400
400
1432.5
28.7
93.1
93.80%
710
