Description
We offer various kinds of permanent magnetic generator from 0.1KW-1500KW(vertical and horizontal), speed from 30rpm to 10000rpm ,voltage,shaft, frequency,power ,speed all can customize, please contact us for more detail informations.
Features of Permanent Magnet Generator
*Low start up speed, Gearless, low RPM generator
*High standard components for use in hard and extreme Environments for wind turbine
*High efficiency low mechanical resistance energy loss
*Design for reliable long operational lifetim
1WM1800rpm690V60Hz Specifciation 1 Rated power:1000kW
2 Rated speed:1800RPM
3 Rated Voltage:690VAC
4 Rated Current(A):839A 5 Efficiency(%):96.7%
6 Connectiong:Y
8 Poles:4
9 Pressure resistance(Ma):<70mA 10 Insult grade:H
11Rated torque(Nm):5320Nm 12Tempeature(ºC):90ºC
13 Maxium temperature(ºC):130ºC 14Cooling:Air cooling
16 Protect:IP54
17 Bearing type: SKF 18 Weight:about 2600kg
Features of Permanent Magnet Generator
*Low start up speed, Gearless, low RPM generator
*High standard components for use in hard and extreme Environments for wind turbine
*High efficiency low mechanical resistance energy loss
*Design for reliable long operational lifetim
1WM1800rpm690V60Hz Specifciation 1 Rated power:1000kW
2 Rated speed:1800RPM
3 Rated Voltage:690VAC
4 Rated Current(A):839A 5 Efficiency(%):96.7%
6 Connectiong:Y
8 Poles:4
9 Pressure resistance(Ma):<70mA 10 Insult grade:H
11Rated torque(Nm):5320Nm 12Tempeature(ºC):90ºC
13 Maxium temperature(ºC):130ºC 14Cooling:Air cooling
16 Protect:IP54
17 Bearing type: SKF 18 Weight:about 2600kg
